Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Basic Step Angle (Full) |
N/A 0.072 º |
Basic Step Angle (Half) |
N/A 0.036 º |
Rotor Moment of Inertia |
N/A 68 g/cm² |
Winding Resistance |
N/A 2.2 Ω |
Rated Phase Current |
N/A 0.75 A |
Motor Length |
N/A 74.5 mm |
Shaft Type |
N/A Dual Shaft |
Reduction Ratio |
N/A 1:10 |
Wire Connection |
N/A Pentagon |
Protection Structure |
N/A Ingress Protection (IP) 30 |
Approval |
N/A European Conformities (CE) |
Allowable Speed Range |
N/A 0 to 180 rpm |
Backlash |
N/A ±35 in0.58 º |
Electromagnetic Brake Rated Excitation Direct Current (DC) Voltage |
N/A 24VDC at equals ±10%(no-polarity) V |
Rated Excitation Direct Current (DC) Voltage |
N/A 24 V |
Rated Excitation Direct Current (DC) Voltage Tolerance (±) (No Polarity) |
N/A 10 % |
Rated Excitation Current |
N/A 0.2 A |
Static Friction Torque |
N/A 1.8 kgf·cm |
Rotation Part Inertia Moment |
N/A 3 x 10-7 kgf.cm² |
B Type Brake |
N/A Power off: Brake is Operating Power on: Brake is Released |
Maximum Operating Time |
N/A 15 ms |
Maximum Releasing Time |
N/A 25 ms |
Shipping Weight |
N/A 0.68 kg |
Unit Weight |
N/A 0.58 kg |
Basic Step Angle |
N/A 0.072 A |
Motor Shaft |
N/A Dual Shaft |
Frame Size |
N/A 42 mm |
Motor Type |
N/A Geared Build-in |
Rated Current per Phase |
N/A 0.75 A |
Rotor Inertia |
N/A 68 g.cm |
Resistance per Phase |
N/A 2.2 Ω |
Maximum Allowable Torque |
N/A 15 kgf.cm |
Allowable Angle |
N/A 0 to 180 |
Gear Ratio |
N/A 1:10 |
Weight |
N/A 13.23 lb |
