Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Protection Structure |
N/A Ingress Protection (IP) 30 |
Resolution |
N/A 16,000PPR (4,000PPR×4-multiply) |
Output Phase |
N/A A, at (A^) B, at (B^) Z, at (Z^) |
Maximum Holding Torque |
N/A 0.714 kgf·cm |
Rotor Moment of Inertia |
N/A 8 g/cm² |
Winding Resistance |
N/A 2.1 O |
Rated Current per Phase |
N/A 1.2 A |
Operation Method |
N/A Bipolar |
Environment Ambient Temperature |
N/A 0 to 50 ºC |
Environment Storage Temperature |
N/A -20 to 70 ºC |
Maximum Response Frequency |
N/A 1000 kHz |
Motor Length |
N/A 41.5 mm |
Shaft Type |
N/A Single shaft |
Environment Ambient Relative Humidity (RH) |
N/A 20 to 85 % |
Environment Storage Relative Humidity (RH) |
N/A 15 to 90 % |
Approximate Weight |
N/A 0.180 kg0.278 kg |
Applied Motor |
N/A 2-Phase |
Number of Axes |
N/A 1 |
