Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Protection Structure |
N/A Ingress Protection (IP) 30 |
Resolution |
N/A 10,000PPR (2,500PPR×4-multiply) |
Output Phase |
N/A A, at (A^) B, at (B^) Z, at (Z^) |
Maximum Holding Torque |
N/A 6.12 kgf·cm |
Rotor Moment of Inertia |
N/A 140 g/cm² |
Winding Resistance |
N/A 0.55 O |
Rated Current per Phase |
N/A 3.5 A |
Operation Method |
N/A Bipolar constant current Drive |
Environment Ambient Temperature |
N/A 0 to 50 ºC |
Environment Storage Temperature |
N/A -20 to 70 ºC |
Maximum Response Frequency |
N/A 300 kHz |
Motor Length |
N/A 112.1 mm |
Shaft Type |
N/A Single shaft |
Environment Ambient Relative Humidity (RH) |
N/A 20 to 85 % |
Environment Storage Relative Humidity (RH) |
N/A 15 to 90 % |
Approximate Weight |
N/A 1.15 kg1.30 kg |
Approval |
N/A European Conformities (CE) |
