Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Protection Structure |
N/A Ingress Protection (IP) 30 |
Resolution |
N/A 10,000PPR (2,500PPR×4-multiply) |
Maximum Holding Torque |
N/A 0.789 N·m |
Rotor Moment of Inertia |
N/A 145 x 10-7 kg·cm² |
Winding Resistance |
N/A 0.43 O |
Rated Current per Phase |
N/A 3.5 A |
Operation Method |
N/A Bipolar |
Motor Length |
N/A 42 mm |
Shaft Type |
N/A Single shaft |
Inductance Measure Per Phase |
N/A 1.3 |
Approximate Unit Weight (Packaged) |
N/A 0.51 kg0.71 kg |
