Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Protection Structure |
N/A Ingress Protection (IP) 30 |
Resolution |
N/A 10,000PPR (2,500PPR×4-multiply) |
Output Phase |
N/A A B Z |
Maximum Holding Torque |
N/A 2.4 N·m |
Rotor Moment of Inertia |
N/A 920 x 10-7 kg·cm² |
Winding Resistance |
N/A 0.8 O |
Rated Current per Phase |
N/A 3.5 A |
Operation Method |
N/A Bipolar |
Environment Ambient Temperature |
N/A 0 to 50 ºC |
Environment Storage Temperature |
N/A -20 to 70 ºC |
Maximum Response Frequency |
N/A 300 kHz |
Motor Length |
N/A 87.8 mm |
Shaft Type |
N/A Single shaft |
Applied Motor |
N/A 2-Phase |
Number of Axes |
N/A 1 |
Motor Environment Ambient Relative Humidity (RH) |
N/A 20 to 85 % |
Motor Environment Storage Relative Humidity (RH) |
N/A 15 to 90 % |
Approval |
N/A European Conformities (CE) Korean Certification Restriction of Hazardous Substances (RoHS) |
Inductance Measure Per Phase |
N/A 3.7 |
Approximate Unit Weight (Packaged) |
N/A 1.40 kg1.54 kg |
