Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Driver Unit Packaged Weight |
N/A ≈ 350 g≈ 500 g |
Applied Motor |
N/A 2-Phase |
Driver Direct Current (DC) Voltage Power Supply |
N/A 24 V |
Maximum Driver Run Current Per Phase |
N/A 0.6 A |
Driver Protection Structure |
N/A Ingress Protection (IP) 20 (International Electrotechnical Commission (IEC) Standard) |
Driver Applied Motor |
N/A shaft type, 2-phase closed-loop stepper motor(Ai-M-20LA) |
Frame Size |
N/A 20 |
Driver Maximum Power Consumption |
N/A 60 W |
Driver Environment Ambient Temperature |
N/A 0 to 50 ºC |
Driver Environment Storage Temperature |
N/A -10 to 60 ºC |
Driver Environment Ambient Relative Humidity (RH) |
N/A 35 to 85 % |
Driver Environment Storage Relative Humidity (RH) |
N/A 10 to 90 % |
Driver Approval |
N/A European Conformities (CE) Korean Certification Restriction of Hazardous Substances (RoHS) |
Motor Environment Ambient Relative Humidity (RH) |
N/A 20 to 85 % |
Motor Environment Storage Relative Humidity (RH) |
N/A 15 to 90 % |
Motor Approximate Weight |
N/A 0.120 kg0.219 kg |
Motor Environment Ambient Temperature |
N/A 0 to 50 ºC |
Motor Environment Storage Temperature |
N/A -20 to 70 ºC |
Motor Maximum Holding Torque |
N/A 0.357 N.m |
Motor Rotor Moment of Inertia |
N/A 2 g/cm² |
Motor Rated Current Per Phase |
N/A 0.6 A |
Motor Winding Resistance |
N/A 310.5 O |
Motor Basic Step Angle [Full/Half] |
N/A 0.9 º1.8 º |
Motor Operation Method |
N/A Bipolar |
Motor Protection Structure |
N/A Ingress Protection (IP) 30 |
Motor Resolution |
N/A 4,000PPR (1,000PPR x 4-multiply) |
Motor Output Phase |
N/A A, B, Z |
Motor Maximum Response Frequency |
N/A 200 kHz |
Motor Approval |
N/A European Conformities (CE) Korean Certification Restriction of Hazardous Substances (RoHS) |
Motor Motor Length |
N/A 53.1 mm |
