Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Driver Direct Current (DC) Voltage Power Supply |
N/A 24 V |
Maximum Driver Run Current Per Phase |
N/A 3.5 A |
Driver Protection Structure |
N/A Ingress Protection (IP) 20 |
Driver Applied Motor |
N/A shaft type, built-in brake type 2-phase closed-loop stepper motor(Ai-M-60SA-B) |
Frame Size |
N/A 60 |
Driver Maximum Power Consumption |
N/A 240 W |
Driver Environment Ambient Temperature |
N/A 0 to 50 ºC |
Driver Environment Storage Temperature |
N/A -10 to 60 ºC |
Driver Environment Ambient Relative Humidity (RH) |
N/A 35 to 85 % |
Driver Environment Storage Relative Humidity (RH) |
N/A 10 to 90 % |
Driver Approximate Weight |
N/A 300 g460 g |
Driver Operation Method |
N/A Bipolar constant current Drive |
Driver Output |
N/A In-Position, Alarm, Warning, Compare 1 / 2, general output (OUT0 to 8) |
Operation Mode |
N/A CONTINUOUS INDEX JOG PROGRAM |
Communication Type |
N/A RS485 |
Communication Protocol |
N/A Modbus RTU |
Applied Library |
N/A C programming language(provided DLL) |
