Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Driver Alternating Current (AC) Voltage Power Supply |
N/A 200 to 240 V |
Maximum Driver Run Current Per Phase |
N/A 2 A |
Driver Protection Structure |
N/A Ingress Protection (IP) 20 |
Driver Applied Motor |
N/A 2-phase closed loop stepper motor |
Frame Size |
N/A 86 |
Driver Maximum Power Consumption |
N/A 250 W |
Driver Environment Ambient Temperature |
N/A 0 to 50 ºC |
Driver Environment Storage Temperature |
N/A -10 to 60 ºC |
Driver Environment Ambient Relative Humidity (RH) |
N/A 35 to 85 % |
Driver Environment Storage Relative Humidity (RH) |
N/A 10 to 90 % |
Driver Approval |
N/A European Conformities (CE) |
Driver Approximate Weight |
N/A 780 g900 g |
Driver Operation Method |
N/A Bipolar constant current Drive |
Driver Output |
N/A B, at (B^) In-Position, Alarm Out, Encoder signal (A, at (A^) Z, at (Z^)) |
