Specifications

Brands

 N/A Autonics USA

Type

 N/A Independent Type

Main Features

 N/A S-Shaped Acceleration/Deceleration

Input and Output Contact

 N/A Parallel I/F: 13/4 X-Axis: 8/6 (General: 2/2) Y-Axis: 8/6 (General: 2/2)

Interpolations

 N/A 2-axis linear interpolation, circle interpolation, arc interpolation

Operation Mode

 N/A CONTINUOUS INDEX JOG Program (200-step)

In-Position Setting

 N/A Absolute Incremental

Direct Current (DC) Voltage

 N/A 24 V

Environment Ambient Temperature

 N/A 0 to 45 ºC

Environment Ambient Storage Temperature

 N/A -15 to 70 ºC

Approval

 N/A European Conformity (CE) Korean Certification (KC)

Environment Ambient Relative Humidity (RH)

 N/A 20 to 90 %

Environment Ambient Storage Relative Humidity (RH)

 N/A 20 to 90 %

Approximate Weight

 N/A 101.6 g308.7 g

Weight

 N/A 0.44 lb

Communication Protocol

 N/A Modbus Remote Terminal Unit (RTU) RS232C Universal Serial Bus (USB)

Drive Speed

 N/A 1 pps to 4 Mpps

Connection Method

 N/A Universal Serial Bus (USB)

Applied Library

 N/A C Programming Language (Provided DLL)

Control Axis

 N/A 2

Output for Common

 N/A 2 Point

Index Step Numbers Per Axis

 N/A 64

Accessories

Accessories

 N/A
  • [Common] Power connector, I/O connector: 3 (PI/F, X-axis, Y-axis), RS232C Communication cable (1.5 m): 1
  • [USB type] USB Communication cable 1m: 1
  • [RS485 type] RS485 connector: 1

Input/Output

Input/Output

 N/A
  • Parallel I/F (CN3): 13 inputs, 4 outputs
  • X-axis (CN4) / Y-axis (CN5): 8 inputs, 6 outputs (general-purpose I/O, two of each)

Note

Note

 N/A
  • Program function control 'LID', 'CID', 'FID', 'RID': These Commands are only for PMC-2HSP series.
  • The weight includes packaging. The weight in parenthesis is for unit only.
  • Environment resistance is rated at no freezing or condensation.
