Unit of Measure
Specifications
Shipping Weight |
N/A 298 g |
Brands |
N/A Autonics USA |
Environment Ambient Temperature |
N/A -30 to 80 ºC |
Environment Ambient Storage Temperature |
N/A -30 to 100 ºC |
Note for Environment Ambient Storage Temperature |
N/A The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'. |
Approval |
N/A European Conformities (CE) Recognized Underwriters Laboratories for United states (US) and Canada |
Environment Ambient Relative Humidity (RH) |
N/A 45 to 85 % |
Environment Ambient Storage Relative Humidity (RH) |
N/A 45 to 85 % |
Unit Weight |
N/A 225 g |
Dielectric Strength Alternating Current (AC) Voltage Between Power off Terminals (At 50/60 Hertz (Hz) Frequency for 1 Minute) (Input-Output, Input/Output-Case) |
N/A 2500 V |
Function |
N/A Zero Cross Turn-On |
Mounting Type |
N/A Din Rail Panel |
Rated Load Current |
N/A 20 A |
Control Phase |
N/A 1-Phase |
Heatsink |
N/A Heatsink |
Rated Directing Current (DC) Input Voltage |
N/A 4 to 30 V |
Rated Alternating Current (AC) Load Voltage |
N/A 48 to 480 V |
Weight |
N/A 0.2 lb |
