Unit of Measure

Specifications

Brands

 N/A Autonics USA

Sensing Distance

 N/A 100 mm

Environment Ambient Temperature

 N/A -40 to 60 ºC

Minimum Sensing Target Diameter

 N/A 0.0125 mm

Type

 N/A Standard Type (Bolt Type)

Allowable Bend Radius

 N/A R5

Free Cut

 N/A Yes

Weight

 N/A 0.56 lb

Fiber Optic Cable

Sensing Type

 N/A Diffuse

Head Form

 N/A Standard (M6 Bolt)

Hood Diameter

 N/A 6 mm

Cable Length

 N/A 2 m

Cable Type

 N/A Break Resistant (R5)

Fiber Diameter

 N/A 1.3 mm

Note

Note

 N/A
  • The sensing distance is a standard for BF5 Series.
  • Minimum sensing target is a value measured opaque material in accurate output status and the sensing distance is different with the rated sensing distance.
  • Flexible optical fiber (Multi core): A large number of ultra-fine cores are all surrounded by cladding. Easy to install it in the many places as the change of the intensity of radiation by bending is small. Break-resistant optical fiber: The fiber units contain a large number of independent fine fibers, by ensuring a high degree of flexibility. It can be used for moving parts (robot hand) and it is not easily broken.
  • Free cut type's sensing distance can be shortened about max. 20% than the normal according to condition of the cable. [(FC-3) should be used for cutting fiber cable.
  • Glass type is for BF5, BF4 Series.
