Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Pressure Type |
N/A Compound |
Connection Type |
N/A Cable |
Cable Length |
N/A 3 m |
Environment Ambient Temperature |
N/A 0 to 50 ºC |
Environment Storage Temperature |
N/A -10 to 60 ºC |
Environment Ambient Relative Humidity (RH) |
N/A 35 to 85 % |
Environment Storage Relative Humidity (RH) |
N/A 35 to 85 % |
Front Case Material |
N/A Polycarbonate (PC) |
Rear Case Material |
N/A Polycarbonate (PC) |
Pressure Port Material |
N/A Nickel Plated Brass |
Applicable Fluid |
N/A (Pneumatic type) Air, Non-corrosive gas |
Pressure Port |
N/A R1/8 |
Rated Pressure Range |
N/A -101.3 to 100.0 kPa |
Protection Structure |
N/A Ingress Protection (IP) 40 |
Approval |
N/A European Conformity (CE) |
Option Output |
N/A Current Output (DC4-20 mA) |
Sold Separately |
N/A Sensor Connector Wire Mount Plug (CNE-P04-YG) |
Shipping Weight |
N/A 60 g |
Unit Weight |
N/A 26 g |
Weight |
N/A 0.2 lb |
