Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Package Type |
N/A Each |
Environment Ambient Temperature |
N/A -15 to 55 ºC |
Environment Storage Temperature |
N/A -25 to 65 ºC |
Protection Structure |
N/A Ingress Protection (IP) 65 (International Electrotechnical Commission (IEC) Standard) |
Approval |
N/A European Conformity (CE) International Electrotechnical Commission (IEC) 60947-5-1 Korean Certification (KC) Underwriters Laboratory for Canada and United States (cULus) Listed |
Note for Approval |
N/A Light Emitting Diode (LED) Blocks are Except KC Certifications |
Environment Ambient Relative Humidity |
N/A 35 to 85 % |
Environment Storage Relative Humidity |
N/A 35 to 85 % |
Approximate Body Weight |
N/A 7.7 g |
Color |
N/A White |
Approximate Weight (Housing) |
N/A 1.4 g |
Illuminated |
N/A Illuminated |
Right Operation Angle (Mechanical Characteristics) |
N/A 45 º |
Left Operation Angle (Mechanical Characteristics) |
N/A 45 º |
Contact Block Power Alternating Current (AC) Voltage (Electrical Specification) |
N/A 250 V |
Contact Block Power Current (Electrical Specification) |
N/A 3 A |
Operation Type |
N/A 3-Position, Maintained |
Maximum Contact Block Terminal Tensile Force (Mechanical Specification) |
N/A 30 N |
Contact Block Terminal Soldering Time (Mechanical Specification) |
N/A At the End of Tips within 3 sec with 350 ºC |
Soldering Machine |
N/A 30 W |
Contact Block Approximate Weight |
N/A 1.6 g |
Light Emitting Diode (LED) Block Approximate Weight |
N/A 1.9 g |
Weight |
N/A 0.2 lb |
