Specifications
Brands |
N/A Autonics USA |
Package Type |
N/A Each |
Environment Ambient Temperature |
N/A -15 to 55 ºC |
Environment Storage Temperature |
N/A -25 to 65 ºC |
Protection Structure |
N/A Ingress Protection (IP) 52 |
Approval |
N/A European Conformity (CE) Korean Certification (KC) Underwriters Laboratory for Canada and United States (cULus) Listed |
Note for Approval |
N/A Light Emitting Diode (LED) Blocks are Except KC Certifications) |
Environment Ambient Relative Humidity |
N/A 35 to 85 % |
Environment Storage Relative Humidity |
N/A 35 to 85 % |
Contact Block Type |
N/A Singular Type |
Color |
N/A White |
Approximate Weight (Housing) |
N/A 7 g |
Right Operation Angle (Mechanical Characteristics) |
N/A 45 º |
Left Operation Angle (Mechanical Characteristics) |
N/A 45 º |
Contact Block Power Alternating Current (AC) Voltage (Electrical Specification) |
N/A 110 V250 V |
Contact Block Power Current (Electrical Specification) at 110 VAC |
N/A 10 A |
Contact Block Power Current (Electrical Specification) at 250 VAC |
N/A 6 A |
Singular Type A/B Contact Block Approximate Weight |
N/A 11 g |
Operation Type |
N/A Long Lever 3-Position, Maintained |
Number of A Contact Block |
N/A 2 |
Approximate Weight (22/25 Millimeter (mm) Diameter Mounting Hole) |
N/A 19 g |
Weight |
N/A 0.2 lb |
