Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Minimum Order |
N/A 10 |
Package Type |
N/A Each |
Environment Ambient Temperature |
N/A -15 to 55 ºC |
Environment Storage Temperature |
N/A -25 to 65 ºC |
Protection Structure |
N/A Ingress Protection (IP) 50 |
Approval |
N/A European Conformity (CE) Korean Certification (KC) Recognized Underwriters Lab for US and Canada (cRUus) |
Note for Approval |
N/A Light Emitting Diodes (LED) Blocks are Except Certifications |
Environment Ambient Relative Humidity |
N/A 35 to 85 % |
Environment Storage Relative Humidity |
N/A 35 to 85 % |
Contact Block Type |
N/A Singular Type |
Light Emitting Diode (LED) Block Alternating Current (AC) Power Voltge |
N/A 12 to 24 V |
Light Emitting Diode (LED) Block Direct Current (DC) Power Voltage |
N/A 12 to 24 V |
Light Emitting Diode (LED) Block Frequency |
N/A 50 Hz60 Hz |
Color |
N/A White |
Approximate Weight (Housing) |
N/A 7 g |
Button Type |
N/A [Illuminated] Extended |
Contact Block Power Alternating Current (AC) Voltage (Electrical Specification) |
N/A 110 V250 V |
Contact Block Power Current (Electrical Specification) at 110 VAC |
N/A 10 A |
Contact Block Power Current (Electrical Specification) at 250 VAC |
N/A 6 A |
Singular Type A/B Contact Block Approximate Weight |
N/A 11 g |
Number of A Contact Block |
N/A 1 |
Number of B Contact Block |
N/A 1 |
Approximate Weight (22/25 Millimeter (mm) Diameter Mounting Hole) |
N/A 14.5 g |
Maximum Light Emitting Diode (LED) Block Current Consumption |
N/A 20 mA |
Alternating Current (AC)/Direct Current (DC) Voltage Type Light Emitting Diode (LED) Block Weight |
N/A 11 g |
Mounting Hole |
N/A 22 mm25 mm |
Contact |
N/A A 1 B 1 (Normally Open (NO) and Normally Closed (NC)) |
Number of Contact |
N/A 2 |
Weight |
N/A 1 lb |
Light Emitting Diode (LED) Direct Current (DC) Voltage |
N/A 12 to 30 V |
Push Button |
N/A Double |
