Unit of Measure
Specifications
Brands |
N/A Autonics USA |
Package Type |
N/A Each |
Environment Ambient Temperature |
N/A -15 to 55 ºC |
Environment Storage Temperature |
N/A -25 to 65 ºC |
Protection Structure |
N/A Ingress Protection (IP) 52 |
Approval |
N/A European Conformity (CE) Korean Certification (KC) Recognized Underwriters Lab for US and Canada (cRUus) |
Note for Approval |
N/A Light Emitting Diodes (LED) Blocks are Except Certifications |
Environment Ambient Relative Humidity |
N/A 35 to 85 % |
Environment Storage Relative Humidity |
N/A 35 to 85 % |
Contact Block Type |
N/A Modular Type |
Light Emitting Diode (LED) Block Alternating Current (AC) Power Voltge |
N/A 110 to 220 V |
Light Emitting Diode (LED) Block Frequency |
N/A 50 Hz60 Hz |
Color |
N/A Green |
Approximate Weight (Housing) |
N/A 7 g |
Right Operation Angle (Mechanical Characteristics) |
N/A 90 º |
Left Operation Angle (Mechanical Characteristics) |
N/A 90 º |
Contact Block Power Alternating Current (AC) Voltage (Electrical Specification) |
N/A 110 V250 V |
Contact Block Power Current (Electrical Specification) at 110 VAC |
N/A 10 A |
Contact Block Power Current (Electrical Specification) at 250 VAC |
N/A 6 A |
Approximate Weight (30 Millimeter (mm) Diameter Mounting Hole) |
N/A 21 g |
Operation Type |
N/A Long Lever 3-Position, Maintained |
Number of A Contact Block |
N/A 1 |
Number of B Contact Block |
N/A 1 |
Modular Type A/B Contact Block Approximate Weight |
N/A 10 g |
Maximum Light Emitting Diode (LED) Block Current Consumption |
N/A 20 mA |
Alternating Current (AC) Voltage Type Light Emitting Diode (LED) Block Weight |
N/A 12 g |
Weight |
N/A 0.2 lb |
